Werkstoffe, Eigenschaften

Werk-
stoffnr.
EN 10027-2 		Stahl-
sorte
EN		Stahl-
sorte
DIN		Streck-
grenze ReH min.		Zug-
festig-
keit Rm min.		Bruch- deh-
nung 		Kerb
schlag- biege-
ver-
such 		Kohlen-
stoff- äqui-valent 		C max SI max Mn max P max S max N max Al max Cr max Mo max Ni max V max Cu max Nb max Ti max
1.0252L 235St 37.0235360 – 500250,160,351,200,0300,025
1.0260L 275St 44.0275430 – 570210,200,401,400,0300,025
1.0419L 355St 52.0355500 – 650 210,220,551,600,0300,025
EN 10216-1 / DIN 1629 nahtlos T ≤ 16
1.0107 P 195 TR 1St 33195320 – 440270,130,350,700,0250,0200,300,080,300,02 0,300,0100,04
1.0254P 235 TR 1St 37.0235360 – 500250,160,351,200,0250,0200,300,080,300,02 0,300,0100,04
1.0258P 265 TR 1St 44.0265410 – 570210,200,401,400,0250,0200,300,080,300,02 0,300,0100,04
1.0108P 195 TR 2St 33195320 – 440270,130,350,700,0250,0200,300,080,300,02 0,300,0100,04
1.0255P 235 TR 2St 37.4235360 – 500250,160,351,200,0250,0200,300,080,300,02 0,300,0100,04
1.0259P 265 TR 2St 44.0265410 – 570210,200,401,400,0250,0200,300,080,300,02 0,300,0100,04
EN 10216-2 / DIN 17175 nahtlosT ≤ 16   250°C
1.0348P 195 GHUH 11951302740 / 0°0,130,350,700,0250,0200,0200,300,080,300,020,300,0100,04
1.0345P 235 GHSt 35.8 / H12351502540 / 0°0,160,351,200,0250,0200,0200,300,080,300,020,300,0100,04
1.0425P 265 GH St 45.82651712340 / 0°0,200,401,400,0250,0200,0200,300,080,300,020,300,0100,04
1.541516Mo 315Mo32802052240 / 20°0,12 – 0,20 0,350,700,0250,020< 0,0400,300,25 – 0,35 0,300,30
1.733513CrMo 4-513CrMo 4 42902362240 / 20°0,10 – 0 , 1 7 0,351,200,0250,020< 0,0400,70 – 1,15 0,40 – 0,60 0,300,30
1.733510CrMo 9-1010CrMo 9 102802242240 / 20°0,08 – 0,14 0,401,400,0250,020< 0,0402,00 – 2,50 0,90 – 1 , 10 0,300,30
EN10216-3 / DIN 1629 nahtlosT ≤ 20
1.0562P 355 NSt 52.0355490 – 650220,200,50 0,90 – 1,70 0,0250,0200,0200,0200,300,080,500,100,300,0500,04
EN 10217-1 / DIN 1626 geschweißtT ≤ 16
1.0107P 195 TR 1St 33195320 – 440270,130,350,700,0250,0200,300,080,30 0,020,30 0,0100,04
1.0254P 235 TR 1St 37.0235360 – 500250,160,351,200,0250,0200,300,080,30 0,020,30 0,0100,04
1.0258P 265 TR 1St 44.0265410 – 570210,200,401,400,0250,0200,300,080,30 0,020,30 0,0100,04
1.0108P 195 TR 2St 33 195320 – 440270,130,350,700,0250,0200,300,080,30 0,020,30 0,0100,04
1.0255P 235 TR 2St 37.4235360 – 500250,160,351,200,0250,0200,300,080,30 0,020,30 0,0100,04
1.0259P 265 TR 2St 44.0265410 – 570210,200,401,400,0250,0200,300,080,30 0,020,30 0,0100,04
EN 10217-2
1.0348P 195 GHSt 33195320 – 440270,130,350,700,0250,0200,300,080,300,020,300,0100,03
1.0345P 235 GHSt 37.8235360 – 500250,160,351,200,0250,0200,300,080,300,020,300,0100,03
1.0425P 265 GHSt 42.8265410 – 570230,200,401,400,0250,0200,300,080,300,020,300,0100,03
1.541516 MO315 MO3280450 – 600220,12 – 0,20 0,350,40 – 0,900,0250,0200,300,300,30
EN 10297-1 nahtlosT ≤ 16
1.0580E 355 N355470 – 490200,220,551,600,0300,035
EN 10210 / DIN 17120 geschweißt DIN 17121 nahtlos
unlegierter BaustahlT ≤ 16
1.0039S 235 JRHR St 37 - 2235360 – 5102627 / 20°0,370,171,400,0400,0400,009
1.0149S 275 JOHSt 44 - 2275430 – 5802327 / 0°0,410,201,500,0350,0350,009
1.0138S 275 J2HSt 44 - 3 N275430 – 5802327 /-20°0,410,201,500,0300,030
1.0547S 355 JOHSt 52 - 3 U355510 – 6802227 / 0° 0,450,220,551,600,0350,0350,009
1.0576S 355 J2HSt 52 - 3 N355510 – 6802227 /-20°0,450,220,551,600,0300,030
Feinkornbaustahl
1.0493S 275 NHStE 285 N275370 – 5102440 /-20°0,400,200,400,50 – 1,400,0350,030 0,0150,0200,300,100,300,080,350,0500,03
1.0497S 275 NLHT StE 285 N275370 – 5102427 /-50°0,400,200,400,50 – 1,400,0300,0250,0150,0200,300,100,300,080,350,0500,03
1.0539S 355 NHStE 355 N355470 – 630 2240 /-20°0,430,200,500,90 – 1,650,0350,030 0,0200,0200,300,100,300,120,350,0500,03
1.0549S 355 NLHT StE 355 N355470 – 630 2227 /-50°0,430,180,500,90 – 1,650,0300,0250,0200,0200,300,100,300,120,350,0500,03
1.8953S 460 NHStE 460 N460540 – 7201740 /-20°0,530,220,601,00 – 1,700,0350,030 0,0250,0200,300,100,300,200,700,0500,03
1.8956S 460 NLHT StE 460 N460540 – 7201727 /-50°0,530,220,601,00 – 1,700,0300,0250,0250,0200,300,100,300,200,700,0500,03
MPaMPaA5 längs min %KV J/°CCEV max. %%%%%%%%%%%%%%%
EN 10255 / DIN 2440 / 2441 nahtlos und geschweißt
1.0026S 195 TSt 33195 320 – 520 0,20 1,40
EN 10224 / DIN 2460 nahtlos und geschweißt
